Products

Home Solar Module P Type PERC

560Watt PERC Half Cell 182MM Mono Solar Panel

PERC 182MM

Item NO.:
HT560M-72H
Color:
Sliver Frame
Size:
2279*1134*30MM
Solar Cell:
182*182mm
Number of Cells:
144(6*24)
Power Range:
540-565W
Certificate:
CE/TUV/UL
Lead Time:
10 Days
Warranty:
25 Years

Description

HITEK monocrystalline solar panels use half cell PERC cells,it has a passivated rear side and a laser grooving process,which significantly improves the cell efficiency,power range from 540-560w.Passed IEC 61215, IEC 61730,UL 61730,INMETRO test for harsh environment.

*High module conversion efficiency *Withstanding harsh environment

*Excellent Anti-PID performance *Excellent weak light performance

Module Type	HT545M-72H		HT550M-72H		HT555M-72H		HT560M-72H		HT565M-72H
	STC	NMOT	STC	NMOT	STC	NMOT	STC	NMOT	STC	NMOT
Maximum Power(Pmax/W)	545	406	550	410	555	414	560	418	565	422
Operating Voltage(Vmp/V)	40.81	38.25	40.90	38.42	40.99	38.59	41.08	38.76	41.17	38.93
Operating Current(Imp/A)	13.36	10.62	13.45	10.68	13.54	10.73	13.64	10.79	13.74	10.85
Open-Circuit Voltage(Voc/V)	49.54	46.77	49.64	46.87	49.74	46.97	49.84	47.07	49.94	47.17
Short-Circuit Current(Isc/A)	13.93	11.26	14.00	11.32	14.07	11.38	14.14	11.44	14.21	11.50
Module Efficiency(%)	21.09		21.29		21.48		21.67		21.87

STC: Irradiance 1000W/㎡,Cell Temperature 25°C,Air Mass AM1.5 NMOT: Irradiance at 800W/㎡,Ambient Temperatue 20°C,Air Mass AM1.5,Wind Speed 1 m/s
